ER2074 Thermally Conductive Epoxy Resin Thumbnail

ER2074

Thermally Conductive Epoxy Resin

ER2074 is a flame retardant system two component epoxy resin with UL94 V-0 approval with high thermal conductivity value of 1.26W/m.K.

Product Codes

250G Resin Pack - ER2074RP250G
1kg Kit - ER2074RP250G
5kg Kit - ER2074K5K
10kg Kit - ER2074K10K

Product Description

ER2074 Thermally conductive epoxy resin is a flame retardant system with UL94 V-0 approval. The flame retardant technology used is halogen free leading to relatively low toxicity fumes and low smoke emission and the lack of abrasive fillers means that there is lower wear on dispensing machinery.

ER2074 has a high thermal conductivity value of 1.26W/m.K. while also offering good chemical and water resistance.

Once cured, the white colour gives a good aesthetic finish and can be very effective as part of thermal management solutions in LED applications, for both external and internal lighting systems.

For more information please refer to the TDS, our technical support team are also on hand to discuss your application requirements further.

Key properties

  • High thermal conductivity; 1.26W/m.K
  • Good environmental protection
  • Good Water resistance
  • Chemical resistant
  • Does not contain abrasive fillers; low wear on dispensing machinery
  • Two part white epoxy resin
  • Meets UL94 V-0 approval
  • RoHS Compliant
