DCA SCC3 Conformal Coating Thumbnail

DCA

SCC3 Conformal Coating

DCA is a unique Modified Alkyd conformal coating specifically formulated to meet the highest defence standards in both Europe and the United States.

Product Codes

200ml Aerosol - DCA200H
1L Bulk - DCA01L
5L Bulk - DCA05L

Product Description

DCA SCC3 Conformal Coating is a unique modified alkyd coating specifically formulated to meet the highest defence standards in both Europe and the United States. Based on a modified alkyd, it is a highly flexible coating making it ideal for small or delicate components. DCA also maintains protection through an extremely wide operating temperature range. It provides excellent chemical resistance to a wide range of chemicals and solvents such as those found in the automotive and aerospace industries making it an excellent choice for these industries.

DCA SCC3 Conformal Coating can be sprayed, dipped or brushed, containing a UV trace, which allows inspection of the PCB after coating to ensure complete and even coverage; the stronger the reflected UV light, the thicker the coating layer is. UV light in the region of 375nm should be used for inspection.

For full product details including test results please refer to the TDS. If you still require further information please don’t hesitate to get in touch with our dedicated technical support team.

Also available as Red Opaque (DCR) Blue Transparent (DCABL) and Black Opaque (DCB)

Key properties

  • High specification flexible modified alkyd resin conformal coating
  • May be ambient cured or heat cured for enhanced performance
  • Excellent chemical and solvent resistance when heat cured
  • May be soldered through for rework
  • Extremely wide operating temperature range resistant to many solvents used within aerospace and automotive industries
  • UL746C-QMJU2
  • DEF-STAN 59/47 (Issue 4)
  • Meets IPC-CC-830
  • RoHS Compliant
