ER2222 Red Thermally Conductive Epoxy Resin Thumbnail

ER2222

Red Thermally Conductive Epoxy Resin

ER2222 is a red variation of Electrolube's ER2221 Thermally conductive Epoxy potting compound. The resins properties are identical to ER2221 but has been formulated with a red finish for aesthetic appearance.

Product Codes

5Kg Kit - EER2222K5K
25kg Kit - EER2222K25K

Product Description

ER2222 red potting compound is a thermally conductive epoxy resin which is a coloured variation of Electrolube’s ER2221 (black). The resins properties are identical to ER2221 but has been formulated with a red finish for aesthetic appearance.

Like Er2221 it’s a highly temperature resistant epoxy potting compound with a wide operating temperature range -40°C to +150°C retaining excellent characteristics even through extensive thermal cycling.

Although ER2222 is a filled system, it is easy to mix and has a low viscosity allowing the resin to flow around and under tricky components or into tight spaces while the fillers used are non-abrasive meaning there is less wear on dispensing equipment.

ER2222 are an excellent choice for encapsulating an electronic device which requires high levels of thermal resistance and protection such as automotive, aerospace, industrial or other applications which are subject to harsh environments.

For more information please refer to the TDS, our technical support team are also on hand to discuss your application requirements further.

Key properties

  • Excellent high temperature resistance up to 150°C
  • Enhanced thermal conductivity
  • Low viscosity for a filled system;
  • Does not contain abrasive fillers; low wear on dispensing machinery
  • Two component red epoxy resin
  • Meets UL94 V-0
  • RoHS Compliant
